40-Pin Single Row Female Header

Headers can be either straight (vertical) or right-angle; the latter form is sometimes used to connect two PCBs horizontally. A row of headers – break to fit.

$2.25$6.25
Pack Qty
resetClear
Add to Wishlist
40-Pin Single Row Female Header
This item: 40-Pin Single Row Female Header
$2.25$6.25
$2.25$6.25
Arduino Stackable Header 2 x 3 Pin 5 Pack
$1.95
1 × 2.54mm 1x40P 17mm Single row header 5 pcs pack

1 in stock (can be backordered)

$2.95
Qty Discount
2 - 4 5%
5 - 9 6.5%
10 + 8%
SKU: N/A
Description
Additional information
Applications
Support & Utility
Q & A
40-Pin Single Row Female Header are  2.54 Pitch and can be cut to the size needed for your project.
Specifications:
  • Female
  • Number of Pins: 40
  • Pin Spacing: 0.1″ (2.54 mm)
  • Height: 8.5mm(Female mount)
  • Length: 2.5m (male pins)
  • Single row
  • Maximum current: 3A
  • Contact Resistance: 20Mohm
  • Contact Retention Force: 500Gf Min
  • Dielectric Withstanding Voltage: 500V Ac(rms) for 1  minute
Package Included: 2.54mm 40-Pin Single Row Female Header 2,5 or 10 pcs pack.

Check out our On Sale and Clearance Items

Development  Resources: Demo Codes, Schematics, Datasheets, Etc



Tempero systems Hackaday     Hackaday serves up Fresh Hacks Every Day from around the Internet.

tempero systems-InstructablesInstructables is a community for people who like to make things. Explore, share, and do your next project with us!

Tempero Systems-Github     Where the world builds software

tempero systems-Raspberry Pi    Raspberry Pi Foundation What would you like to make today?

tempero systems-Arduino    Arduino‘s mission is to enable anyone to enhance their lives through accessible electronics and digital technologies.

tempero systems-Wikipedia     Wikipedia is a free online encyclopedia created and edited by volunteers worldwide and hosted by the Wikimedia Foundation.



Notes:

1. There may be small size Deviations due to manual measurement, different Measuring methods and tools.
2. The picture may not reflect the actual colour of the item because of different Photographing lights, angles and display monitors.



Weight 0.010 kg
Dimensions 10 × 2 × .5 cm
Pack Qty

2 Pack, 5 Pack, 10 Pack
