L293D Motor Drive Shield Expansion Board Mega2560 UNO R3

$8.95 (AUD)

L293D is a monolithic integrated, high voltage, high current, 4-channel driver. Basically, this means using this chip you can use DC motors and power supplies of up to 36 Volts,

5 in stock

Qty Discount
2 + 5%
5 + 10%
SKU: OKY2151 Categories: ,


We Ship World Wide We are an Australian owned and Based Company. We are an Australian owned and Based Company. We are an Australian owned and Based Company. We are an Australian owned and Based Company. We are an Australian owned and Based Company. We are an Australian owned and Based Company. We are an Australian owned and Based Company.

Calculate Shipping - shipping options and estimates can be found in your shopping cart.

Features

L293D Motor Drive Shield Expansion Board Mega2560 UNO R3

  • Can drive 4 DC motors or 2 stepper motors or 2 Servo
  • Up to 4 bi-directional DC motors with individual 8-bit speed selection
  • Up to 2 stepper motors (unipolar or bipolar) with single coil, double coil or interleaved stepping.
  • 4 H-Bridges: per bridge provides 0.6A (1.2A peak current) with thermal protection, can run motors on 4.5V to 36V DC
  • Pull-down resistors keep motors disabled during power-up
  • reset button
  • 2 external terminal power interface, for separate logic/motor power supplies

L293D Motor Drive Shield Expansion Board Mega2560 UNO R3 is a monolithic integrated, high voltage, high current, 4-channel driver. Basically, this means using this chip you can use DC motors and power supplies of up to 36 Volts, that’s some pretty big motors and the chip can supply a maximum current of 600mA per channel. The L293D chip is also what’s known as a type of H-Bridge. The H-Bridge is typically an electrical circuit that enables a voltage to be applied across a load in either direction to an output, e.g. motor.
1.2 Interface for 5V servo connection to the high-resolution dedicated timer – no jitter!

What is Arduino Shield?

Arduino shields are the boards, which are plugged over the Arduino board to expand its functionalities.

For example, Ethernet shields are used to connect the Arduino board to the Internet. The pin position of the shields is similar to the Arduino boards.
