2.8 Inch TFT Shield Touch Display Module with sd card for Arduino and Pen

2.8 Inch TFT Shield Touch Display Spice up your project with a beautiful large touchscreen display shield with a built-in microSD card connection and pen.

$22.65

3 in stock

Add to Wishlist
This item: 2.8 Inch TFT Shield Touch Display Module with sd card for Arduino and Pen

3 in stock

$22.65
$22.65
Nextion NX4024T032 3.2 inch
1 × Nextion NX4024T032 3.2 inch

Out of stock

$55.95
1.3-inch IPS TFT LCD colour module SPI
$13.95
2.2 inch TFT LCD 240 x 320 without Touch ILI9341
$19.95
1.8 Inch LCD TFT Display 128X160 SPI Serial Port With SD Card Holder
$13.95
Qty Discount
2 - 4 5%
5 - 9 6.5%
10 + 8%
SKU: TS-S009
Description
Additional information
Applications
Support & Utility
Q & A

2.8 The Inch TFT Shield Touch Display Module with SD cards for Arduino and Pen is fully assembled, tested, and ready to go. No wiring, no soldering. Works best with any classic (UNO/Duemilanove/Diecimila).

This TFT display is big (2.8 inches diagonal), bright (4 white-LED backlights), and colourful (18-bit 262,000 different shades)! 240 x 320 pixels with individual pixel control.

It has way more resolution than a black and white 128 x 64 display. As a bonus, this display already has a resistive touchscreen to detect finger presses anywhere on the screen.

Features:

  • Supports development boards such as Arduino UNO and Mega2560 for plug-in use without wiring.
  • 240 x 320 resolution, clear display, and support for the touch function.
  • It supports a 16-bit RGB 65K colour display and displays rich colours.
  • 8-bit parallel bus, faster than serial SPI refresh.
  • On-board 5V/3.3V level shifting IC, compatible with 5V/3.3V operating voltage.
  • It is easy to expand the experiment with an SD card slot.
  • Provides an Arduino library with a rich sample program.
  • Military-grade process standards, long-term stable work.
  • Provide underlying driver technical support.
  • This shield is Leonardo-compatible.

Package included: 1 x The 2.8 Inch TFT Shield Touch Display Module with SD card for Arduino and Pen.

Check out our On Sale and Clearance Items

Development  Resources: demo codes, schematics, datasheets, etc

LCD Wiki is an open-source professional display-sharing website



     Hackaday serves up Fresh Hacks Every Day from around the Internet.


Instructables is a community for people who like to make things. Explore, share, and do your next project with us!



     Where the world builds software

    Raspberry Pi Foundation: What would you like to make today?

    Arduino‘s mission is to enable anyone to enhance their lives through accessible electronics and digital technologies.


Wikipedia is a free online encyclopedia created and edited by volunteers worldwide and hosted by the Wikimedia Foundation.



Notes:

1. There may be slight size deviations due to manual measurement, different measuring methods and tools.
2. The picture may not reflect the actual colour of the item because of different photography lights, angles and display monitors.

Weight .046 kg
Dimensions 8 × 6 × 1.8 cm
